Barco HDX Projector User Manual



D. DMX chart
Chan-
nel
Function Value
Default
Actions
0 - 87 No function
88 - 95 Input 1 (if held for 2 seconds)
96 - 103 Input 2 (if held for 2 seconds)
104 - 111 Input 3 (if held for 2 seconds)
112 - 119 Input 4 (if held for 2 seconds)
4 Input selection
120 - 255
0
No function
0 - 7 No function
8 - 15 Lens shift Right
16 - 23 No function
24 - 31 Lens shift Left
32 - 39 No function
40 - 47 Lens shift up
48 - 55 No function
56 - 63 Lens shift down
64 - 231 No function
232 - 239 Return lens to center (if held for 5 seconds)
240 - 247 Calibrate lens zoom + focus (if held for 5 seconds)
5
Lens control
248 - 255
0
No function
6 Focus (MSB) 0 - 255 128 Coarse lens focus adjustment
14
7
Focus (LSB) 0 - 255 128 Fine lens focus adjustment
14
8 Zoom (MSB) 0 - 255 128 Coarse lens zoom adjustment
14
9 Zoom (LSB) 0 - 255 128 Fine lens zoom adjustment
14
0 - 7 Lamp power 100%
8 - 15 Lamp power 95%
16 - 23 Lamp power 90%
24 - 31 Lamp power 85%
32 - 39 Lamp power 80%
40 - 47 Lamp power 75%
48 - 55 Lamp power 70%
56 - 63 Lamp power 65%
64 - 71 Lamp power 60%
72 - 79 Lamp power 55%
80 - 207 No function
208 - 215 Power On / Lamp On (If held for 5 seconds)
216 - 223 Stand by / Lamp Off (if held for 5 seconds)
224 - 231 XLR output voltage On (if held for 5 seconds)
232 - 239 XLR output voltage Off (if held for 5 seconds)
10 Lamp Control
240 - 255
0
No function
14. Only when lens is calibrated
R5905032 HDX SERIES 02/03/2015 319
