8. Input
1
SENSIO
®
Hi-Fi 3D stream
2
Left expansion
3 Right expansion
4
SENSIO
®
Hi-Fi 3D interpolation
5
SENSIO
®
Hi-Fi 3D interpolation
6 Right stream
7
Left stream
SENSIO
®
3D Decoder - FFC is using both the SENSIO
®
3D Decoder as well as the SENSIO
®
Autodetect functionality. This mode
enables an automatic detection of 2D, Top-and-Bottom, Side-by-Side and the SENSIO
®
Hi-Fi 3D format, with a clean transition and
fast detection time between these formats. Only progressive formats are supported. Interlaced formats will be displayed in 2D (one
eye only). The SENSIO
®
Autodetect feature requires a minimum of 1120x540 active pixels per eld/frame to operate.
The acronym FFC stands for ‘Full Frame Compatible’, in other words, the decoder handles all full frame based 3D formats.
Double or triple ash
Double or triple ash is used for 3D sources to avoid ickering images.
Input frequency < 40Hz/eye triple ash will be used and results in:
144Hz for 24Hz/eye input
150Hz for 25Hz/eye input
180Hz for 30Hz/eye input
Input frequency between 40Hz and 51Hz/eye double ash will be used and results in:
192Hz for 48Hz/eye input
200Hz for 50Hz/eye input
Supported formats
DVI/HDMI/DP
5–cable analog DVI analog
SDI
Fpix 210 MHz Fpix 210 MHz Fpix 170 MHz Fpix 150 MHz
Max. resolution:
1920x1200@60Hz or
2048x1080@60Hz.
1400x1050@120Hz or
1600x900@120Hz.
Max. resolution:
1920x1200@60Hz or
2048x1080@60Hz.
1400x1050@120Hz or
1600x900@120Hz.
Max. resolution:
1920x1200@60Hz or
2048x1080@60Hz.
1280x720@120Hz or
1280x800@120Hz.
Max. resolution:
1920x1200@60Hz,
2048x1080@60Hz or
1280x720@120Hz.
Frame sequential
Single channel
Interlaced/progressive Interlaced/progressive Interlaced/progressive Interlaced/progressive
HD formats only.
Max. resolution:
1920x1080@30Hz or
1280x720@60Hz.
HD formats only.
Max. resolution:
1920x1080@30Hz or
1280x720@60Hz.
HD formats only.
Max. resolution:
1920x1080@30Hz or
1280x720@60Hz.
HD formats only.
Max. resolution:
1920x1080@30Hz or
1280x720@60Hz.
Frame Packing
(FHD3D)
Progressive only Progressive only Progressive only Progressive only
Max. resolution:
1920x1200@60Hz or
2048x1080@60Hz.
Max. resolution:
1920x1200@60Hz or
2048x1080@60Hz.
Max. resolution:
1920x1200@60Hz or
2048x1080@60Hz.
Max. resolution:
1920x1200@60Hz or
2048x1080@60Hz.
Side-by-Side
Interlaced/progressive Interlaced/progressive Interlaced/progressive Interlaced/progressive
Max. resolution:
1920x1200@60Hz or
2048x1080@60Hz.
Max. resolution:
1920x1200@60Hz or
2048x1080@60Hz.
Max. resolution:
1920x1200@60Hz or
2048x1080@60Hz.
Max. resolution:
1920x1200@60Hz or
2048x1080@60Hz.
Top-and-Bottom
Progressive only Progressive only Progressive only Progressive only
