Barco HDX Projector User Manual



5. Getting started
5. GETTING STARTED
Overview
RCU & Local keypad
Terminology overview
Power on projector
Switching to standby
Power off projector
Status LEDs
Using the RCU
Projector Address
Source selection
5.1 RCU & Local keypad
How controlling the projector ?
The projector can be controlled by the local keypad or by the remote control unit.
Location of the local keypad ?
The local keypad is located on the input side of the projector.
Remote control functions.
This remote control includes a battery powered infrared (IR) transmitter that allows the user to control the projector remotely. This
remote control is used for source selection, control, adaptation and set up.
Other functions of the remote control are :
switching between stand by and operational mode.
switching to "pause" (blanked picture, full power for immediate restarting)
direct access to all connected sources.
5.2 Terminology overview
Overview
The following table gives an overview of the different functionality of the keys.
R5905032 HDX SERIES 02/03/2015
55
