2. General
One xenon lamp is mounted inside the lamp house at delivery. The projector lenses are not included in the
package of the projector.
Mechanical check
This check should conrm that there are no broken knobs or connectors, that the cabinet and panel surfaces are free of dents and
scratches, and that the operating panel is not scratched or cracked. The Barco Sales and Service ofce should be notied as soon
as possible if this is not the case.
2.4 HDX ight case
Introduction of the HDX ight case
The HDX ight case is designed to transport the HDX projector in a safe and secure manner. The four caster wheels, provided with
breaks, and the four handles make the HDX ight case easy to handle. The oor of the ight case wagon is equipped with two small
covered compartments to store the remote control and the rigging clamps.
Image 2-3
HDX Flight case
Order number ight case: R9864090
The dimensions of the ight case are optimal for maximum utilization of the oor area of a truck. The cover of the HDX ight case
has 4 stacking dishes, which allows to stack the ight cases.
WARNING: Maximum stack two (2) HDX ight cases high. Never higher.
2.5 Projector congurations
The different congurations
Depending on the installation the projector can be mounted in different ways, the different congurations are:
1. Front / Table (F/T)
2. Front / Ceiling (F/C) (upside down)
3. Front / Ceiling (F/C) (table positio
n)
4. Rear / Table (R/T)
5. Rear / Ceiling (R/C) (upside down)
6. Rear / Ceiling (R/C) (table position)
Front projection
The projector is installed, either in a table mount or ceiling mount conguration, at the same side of the screen as the audience.
