Barco HDX Projector User Manual



B. Specifications
Optical lens shift Vertical: -30% to +120% / Horizontal: -40% to +40% on zoom lenses (memorized)
Color correction
P7
Lamps 2.5 kW Xenon
Lamp lifetime (typical)
1,000 hours
Transport with lamp Yes
Lamp house, quick replace Yes
Customer bulb replace
Yes
Lamp warranty (eld replace/
factory replace)
90 days, 500 hours/pro rata 750 hours
Sealed DLP™ core Standard
Optical dowser Standard
Picture-in-picture Two sources simultaneously
Orientation table - ceiling - side (portrait)* - vertical
* lamp door down/bottom
DMX 512
Standard
WARP
direct adjust OSD + toolset
Integrated web server Yes
CLO (constant light output)
standard
3D
active eyewear (optional), passive Intec (optional), passive circular (optional), triple
ash up to 200Hz
Inputs DVI- I (HDCP including analog RGB YUV) / SDI/HDSDI/dual HDSDI/3G/BarcoLink
Optional Inputs 5-BNC RGBHV ( RGBS/RGsB, YUV CS/SOY, Composite video, S-Video); DVI - I (HDCP
including analog RGB YUV) + BarcoLink/SDI/HDSDI/dual HDSDI/3G; 3D active input
(HDMI/ DisplayPort) feat. SENSIO 3D
Input Resolutions
From NTSC up to QXGA (2,048 x 1,536)
Max. pixel clock 200 Mhz
Software tools
Projection Toolset + Android app
Control XLR wired + IR, RS232, Wi, GSM (opt)
Network connection
10/100 Base-T, RJ-45 conn, Wi (optional)
AC power 200-240 V / 50-60 Hz
Power consumption
2,850 W / STBY<8W
Noise level (typical at 25°C/77°F) 53 dB (A)
Operating temperature 0 ~ 40°C / 32 ~ 104°F
operation humidity no condens
0% - 80%
Dissipation BTU
Max. 9,725 BTU/h
Dimensions (WxLxH) 475 x 725 x 382 mm (18.70" x 28.54" x 14.96")
Weight
50kg (110lbs)
Shipping Dimensions (LxWxH) 900 x 650 x 560 mm (35.43" x 25.59" x 22.04")
Standard accessories Power cord; wireless/XLR wired rugged remote control
Certications Compliant with UL60950-1 and EN60950-1, complies with FCC rules & regulations, part
15 Class A and CE EN55022 Class A, RoHS
Warranty 2 years standard, extendable up to 5 years
R5905032 HDX SERIES 02/03/2015 311
