B. Specifications
Picture-in-picture Two sources simultaneously
Orientation table - ceiling - side (portrait)* - vertical
* lamp door down/bottom
DMX 512
Standard
WARP
direct adjust OSD + toolset
Integrated web server Yes
CLO (constant light output)
standard
3D
active eyewear (optional), passive Infitec (optional), passive circular (optional), triple
flash up to 200Hz
Inputs
DVI- I (HDCP including analog RGB YUV)
SDI/HDSDI/dual HDSDI/3G/BarcoLink
Optional Inputs 5-BNC RGBHV ( RGBS/RGsB, YUV CS/SOY, Composite video, S-Video); DVI - I (HDCP
including analog RGB YUV) + BarcoLink/SDI/HDSDI/dual HDSDI/3G; 3D active input
(HDMI/ DisplayPort) feat. SENSIO 3D
Input Resolutions
From NTSC up to QXGA (2,048 x 1,536)
Max. pixel clock 200 Mhz
Software tools
Projection Toolset + Android app
Control - XLR wired, IR, RS-232, DMX512 in/out, integrated web browser, Projection Toolset
- optional control over WiFi and GSM/mobile
Network connection 10/100 Mb/s Ethernet (on RJ45), WiFi
AC power 200-240 V / 50-60 Hz
Power consumption 2,850 W / STBY<8W
Noise level (typical at 25°C/77°F) 53 dB (A)
Operating temperature 0 ~ 40°C / 32 ~ 104°F
operation humidity no condens 0% - 80%
Dissipation BTU Max. 9725 BTU/h
Dimensions (WxLxH) 475 x 725 x 382 mm (18.70" x 28.54" x 14.96")
Weight 50kg (110lbs)
Shipping Dimensions (LxWxH) 900 x 650 x 560 mm (35.43" x 25.59" x 22.04")
Standard accessories Power cord; wireless/XLR wired rugged remote control
Certifications Compliant with UL60950-1 and EN60950-1, complies with FCC rules & regulations, part
15 Class A and CE EN55022 Class A, RoHS
Warranty 2 years standard, extendable up to 5 years
B.4 Specifications of the HDX W20 FLEX
Overview
Projector type
WUXGA 3-Chip DLP digital projector
Technology 0.96" DMD x 3
Resolution 1,920 x 1,200
Light output
20,000 Center lumens / 18,500 ANSI lumens
Contrast ratio 1,850:1 (standard) - 2,400:1 (high contrast mode)
Brightness uniformity 90%
Aspect Ratio 16:10
ScenergiX
horizontal and vertical edge blending
Lens type TLD +
Lens range 0.73:1 ; 1.2:1 ; 1.25-1.6:1 ; 1.5-2.0:1 ; 2.0-2.8:1 ; 2.8-4.5:1 ; 4.5-7.5:1 ; 7.5-11.5:1
310 R5905032 HDX SERIES 02/03/2015
