Creating a Configuration
The current configuration can be changed using the front panel buttons. Change the current
configuration as follows:
1. Press the Esc button to clear any input button indicators, output button indicators, or
control button indicators that may be lit.
2. Select video, audio, or both for configuration by pressing the Video button and Audio
button as necessary.
3. Select the desired input and output(s) by pressing the input and output buttons.
• Input buttons and output buttons light or blink:
• Amber to indicate video and audio ties
• Green to indicate video only ties
• Red to indicate audio only ties
• To indicate potential ties, output buttons blink the appropriate color when an input
is selected.
• To indicate current ties, output buttons light steadily the appropriate color when an
input is selected.
• To clear unwanted outputs, press and release the associated lit output buttons. To
indicate potential unties, output buttons blink the appropriate color when an output
is deselected but not untied from the input.
4. Press and release the Enter button to accept the tie or to break an existing tie.
5. Repeat steps 1 through 4 to create or clear additional ties until the desired configuration
is complete.
NOTES: • Only one video input and one audio input can be tied to an output.
• If a tie is made between an input and an output, and the selected output
was previously tied to another input, the older tie is broken in favor of
the newer tie.
• If an input with no tie is selected, only the button for the selected input
lights.
• When the Video button and the Audio button are lit, if an input with an
audio tie but no video tie is selected, the button for the input and the
button for the output light the appropriate color (amber, green, or red).
• As each input and output is selected, the associated output button blinks
the appropriate color to indicate a tentative tie. Buttons for outputs that
were already tied to the input light the appropriate color steadily. Outputs
that are already tied can be left on, along with new blinking selections, or
toggled off by pressing the associated output button.
• If you press the input button for an input that is I/O grouped (see “I/O
grouping“, on page 39) and then try to select an output in a different
group, you cannot select the associated output button. The associated
input button remains lit.
MTPX Plus Series • Operation 31
