Command and Response Table for SIS Commands
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Create Ties
NOTES: • Commands can be entered back-to-back in a string, with no spaces. For example: 1*1!02*02&003*003%4*8$.
• The quick multiple tie and tie input to all output commands activate all I/O switches simultaneously.
• The matrix switchers support 1-, 2-, and 3-digit numeric entries (1*1, 02*02, or 001*001).
• The & tie command for RGB and the % tie command for video can be used interchangeably on the matrix switchers).
Tie input
X!
to output
X@
, video (V)
and audio (A)
X!
*
X@
! Out
X@
•In
X!
•All
]
Tie the video and audio for input
X!
to
output
X@
.
Example:
1*3!
Out03•In01•All
]
Tie input 1 video and audio to output 3.
Tie input
X!
to output
X@
, RGB
(video) only
X!
*
X@
& Out
X@
•In
X!
•RGB
]
Audio breakaway.
Example (see last Note bullet,
above):
10*4&
Out04•In10•RGB
]
Tie input 10 RGB to output 4.
Tie input
X!
to output
X@
, video only
X!
*
X@
% Out
X@
•In
X!
•Vid
]
Audio breakaway.
Example (see last Note bullet,
above):
7*5%
Out05•In07•Vid
]
Tie input 7 video to output 5.
Tie input
X!
to output
X@
, audio only
X!
*
X@
$ Out
X@
•In
X!
•Aud
]
Audio breakaway.
Example:
12*4$
Out04•In12•Aud
]
Tie input 12 audio to output 4.
Quick multiple tie
E
+Q
X!
*
X@
!...
X!
*
X@
$
}
Qik
]
Example:
E
+Q3*4!3*5%3*6$
}
Qik
]
Tie input 3 video and audio to output
4, tie input 3 video to output 5, and tie
input 3 audio to output 6.
Tie input to all outputs, video and
audio
X!
*! In
X!
•All
]
Example:
5*!
In05•All
]
Tie input 5 video and audio to all
outputs.
NOTE: 0*! clears all ties.
Tie input to all outputs, RGB (video)
only
X!
*& In
X!
•RGB
]
Audio breakaway.
Example (see last Note bullet,
above):
8*&
In08•RGB
]
Tie input 8 RGB to all outputs.
Tie input to all outputs, video only
X!
*% In
X!
•Vid
]
Audio breakaway.
Example (see last Note bullet,
above):
10*%
In10•Vid
]
Tie input 10 video to all outputs.
Tie input to all outputs, audio only
X!
*$ In
X!
•Aud
]
Audio breakaway.
Read ties
NOTE: The & read tie command for RGB and the % read tie command for video can be used interchangeably on the matrix switchers.
Read RGB (video) output tie
X@
&
X!]
RGB input
X!
is tied to output
X@
.
Read video output tie
X@
%
X!]
Video input
X!
is tied to output
X@
.
Read audio output tie
X@
$
X!]
udio input
X!
is tied to output
X@
.
NOTE: X! = Input number 00 – (maximum number of inputs for your model) (00 = untied)
X@ = Output number 01 – (maximum number of outputs for your model)
MTPX Plus Series • Programming Guide 80
