Command/Response Table for SIS Commands (continued)
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Save, recall, and directly write global presets (continued)
Direct write process —
NOTE: The direct write of a global preset should always be preceded by a clear global preset ties command of that same preset number,
as shown below. In a directly-written preset, the input for each output position (or no tied input) remains unchanged unless
overwritten or cleared.
If you do not clear the ties in a global preset number before you directly write a global preset to that number, ties that are part of
the previous version of the specified preset with the same number can unexpectedly become part of the newly-created preset.
Clear global preset ties
E
+
X2#
P0*!
}
Spr
X2#]
Clear all ties in preset
X2#
.
Directly write a global preset
E
+
X2#
P
X!
*
X@
!
X!
*
X@
%
X!
*
X@
$ ...
X!
*
X@
&
}
The tie all (!), tie RGB (&),
tie video (%), and tie audio ($)
commands are all valid.
Spr
X2#]
Example:
E
+27P0*!
}
Spr27
]
Clear all ties in preset 27.
Esc
+27P12*5!10*09%3*2$3*8&
Brackets are shown to separate ties for
clarity only. Create global preset 27,
which ties video and audio input 12 to
output 5, video input 10 to output 9,
audio input 3 to output 2, and video
input 3 to output 8.
Spr27
]
Write room outputs
EX2%
,
X@
1
,
X@
2
, ...
X@
n
MR
]
Mpr
X2%
,
X@
1
,
X@
2
, ...
X@
n
]
See notes.
NOTES: • A room can contain a maximum of 16 outputs (
X@
s).
• An output can belong to only one room.
• The maximum number of rooms (
X2%
s) is 10.
• If no room name is assigned, the default name is “Room #
X2%
.”
Example:
E
8,3,04,5,6MR
}
Mpr8,03,04,05,06
]
Outputs 3, 4, 5, and 6 are
assigned to room 8.
Read room outputs
EX2%
MR
} X2#
,
X@
1
,
X@
2
, ...
X@
n
]
Example:
E
3MR
}
Class 1,01,02,08,09
]
Outputs 1, 2, 8, and 9 are assigned to
room 3, which named “Class 1”.
Recall room preset
X2%
*
X2#
.
Rmm
X2%
•Rpr
X2#]
Command character is a period.
Clear room preset ties
E
+
X2%
*
X2#
P0*!
]
Rmm
X2%
•Spr
X2#]
Clear all ties in room
X2#
preset
X2#
.
Directly write a room preset
E
+
X2%
*
X2#
P
X!
*
X@
!
X!
*
X@
%
X!
*
X@
$ ...
X!
*
X@
&
}
Enter as many ties as are valid for this
model. Tie all (!), tie RGB (&), tie video
(%), and tie audio ($) commands are
all valid.
Rmm
X2%
•Spr
X2#]
Example:
Esc
+7*3P12*7&11*5$4*5%6*6!
Brackets are shown to separate ties for
clarity only. Create preset 3 for room 7,
which ties audio input 12 to output 7,
video input 11 to output 5, RGB input
4 to output 5, and video and audio
input 6 to output 6.
Rmm07•Spr03
]
Lock (executive) modes
NOTE: See “Setting the Front Panel Locks (Executive Modes)” in the “Operation” section for more information on the Lock modes.
Lock all front panel functions
1X
Exe1
]
Enable Lock mode 1.
Lock advanced front panel functions
2X
Exe2
]
Enable Lock mode 2.
Unlock all front panel functions
0X
Exe0
]
Enable Lock mode 0.
View lock status
X
X1#]
NOTE: X! = Input number 01 – (maximum number of inputs for your model)
X@ = Output number 01 – (maximum number of outputs for your model)
X1# = Lock mode 0 = mode 0 1 = mode 1 2 = mode 2
X2# = Global or room preset # 01 - 32, 10 maximum for a room preset
X2% = Room # (for room presets) 10 max. (each can have up to 10 presets (X2#s) assigned)
MTPX Plus Series • Programming Guide 87
