Command/Response Table for SIS Commands (continued)
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Input skew adjustment
NOTE: For the MTPX Plus 128, these commands are valid for inputs 5 through 12 only.
Set all input skew adjustment values
EX#
*
X1)
*
X1)
*
X1)
Iseq
}
Set a specific skew adjustment for the TP
input.
X1)
values are listed in RGB order.
Iseq
X#
*
X1)
*
X1)
*
X1)]
Example:
E
2*0*0*4Iseq
}
Iseq02*00*00*04
]
Set skew settings for input 2 as follows:
Red = 0 ns
Green = 0 ns
Blue = 8 ns (delayed 8 ns).
Increment one input skew
adjustment value
EX#
*
X1!
+Iseq
}
Iseq
X#
*
X1)
*
X1)
*
X1)]
Increase the
X1!
plane skew
adjustment for input
X#
by 1 step (2 ns).
Example:
E
2*2+Iseq
}
Iseq02*00*00*05
]
Increase the blue skew for input 2 by 2 ns
to 10 ns.
Decrement one input skew
adjustment value
EX#
*
X1!
-Iseq
}
IseqX#*
X1)
*
X1)
*
X1)]
Decrease the
X1!
plane skew adjustment
for input
X#
by 1 step (2 ns).
Read input skew adjustment values
EX#
Iseq
} X1)
*
X1)
*
X1)]
EDID commands
NOTE: For the MTPX Plus 128, these commands are valid for inputs 1 through 4 only.
Assign EDID data to an input
E
A
X*
*
X1$
EDID
}
EdidA
X*
*
X1$]
Assign EDID data to all inputs
E
A*
X1$
*EDID
}
EdidA0*
X1$]
Save output #1 EDID data to a user-
defined space
E
S*
X1$
EDID
}
EdidS
X1$]
For this command, the
X1$
value must
be from 31 to 34.
View EDID data assigment
E
A*
X*
EDID
} X1$]
Output pre-peaking
Set output pre-peaking on
EX1@
*1Opek
}
Opek
X1@
*1
]
Pre-peak the TP output.
Set output pre-peaking off
EX1@
*0Opek
}
Opek
X1@
*0
]
Do not pre-peak the TP output.
Read output pre-peaking setting
EX1@
Opek
} X1#]
NOTE: X# = TP input number 01 – (maximum number of TP inputs for your model)
X* = Input number 01 – (maximum number of inputs for your model)
X1) = Skew adjustment range 00 – 31 (each step = 2 ns)
X1! = Video plane 0 = red
1 = green
2 = blue
X1@ = Pre-peakable output number MTPX Plus 168 01 – 04
MTPX Plus 128, 816, 1616, 3216 01 – 08
MTPX Plus 1632, 3232 01 – 16
X1# = Pre-peaking 0 = off
1 = on
X1$ = DDC value (EDID) See page 78.
MTPX Plus Series • Programming Guide 82
