Command/Response Table for SIS Commands (continued)
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
View ties, gain, volume, mutes, presets, and DIP switch status (continued)
View audio global preset
configuration
EX2#
*
X@
*2VC
} X!
n
•
X!
n+1
•
X!
n+1
•
X!
n+2
•...•
X!
n+15
•Aud
]
Show the audio configuration for preset
X2#
. Show the input tied to 16 sequential
outputs, starting from output
X@
.
Command description:
Response description:
preset #*starting output # (StO#)*2(=audio)VC
input # (I#) tied to StO#•I# tied to StO#+1•I# tied to StO#+2• ... •I# tied to StO#15•Aud
]
NOTES: • The starting output number (
X@
) should always be “1” for matrix sizes of 16 outputs or smaller.
•
EX2#
*
X@
*2VC
}
where
X2#
= 0 returns the current audio configuration.
Example: (MTPX Plus 1632)
E
15*17*2VC
}
17Output:
Response = tied input:
input 1 tied to output 19
18 19 20 21 22 23 24
25 26 27 28 29 30 31 32
no tied input
01•01•01•01•02•12•12•00•00•00•00•00•01•08•15•16•Aud
Each position shown in the response is an output: left = starting output (17), right =
starting output +15 (32). The number in each position is the input tied to that output.
In this example, preset 15, audio input 1 is tied to outputs 17, 18, 19, 20, and 29; input 2 is tied
to output 21; input 12 is tied to outputs 22 and 23; input 8 is tied to output 30; input 15 is tied to
output 31; and input 16 is tied to output 32. No input is tied to output 24, 25, 26, 27, and 28.
View video room preset
configuration
EX2%
*
X2#
*1*1VC
} X!
n
•
X!
n+1
•
X!
n+1
•
X!
n+2
•...•
X!
n+15
•Vid
]
Show the video configuration for room
X2%
, preset
X2#
. Show the input tied to
up to 16 outputs assigned to room
X2%
.
Command description:
Response description:
room #*room preset #*starting output # (StO#)*1(=video)VC
input # (I#) tied to StO#•I# tied to StO#+1•I# tied to StO#+2• ... •I# tied to StO#+15•Vid
]
NOTE: The starting output number (
X@
) should always be “1” for matrix sizes of 16 outputs or smaller.
View audio room preset
configuration
EX2%
*
X2#
*1*2VC
} X!
n
•
X!
n+1
•
X!
n+1
•
X!
n+2
•...•
X!
n+15
•Aud
]
Show audio configuration for room
X2%
,
preset
X2#
. Show the input tied to up to
16 outputs assigned to room
X2%
.
Command description:
Response description:
room #*room preset #*starting output # (StO#)*2(=audio)VC
input # (I#) tied to StO#•I# tied to StO#+1•I# tied to StO#+2• ... •I# tied to StO#+15•Aud
]
NOTE: The starting output number (
X@
) should always be “1” for matrix sizes of 16 outputs or smaller.
View Input Select DIP switch
positions and level/peaking status
E
Stat
}
X2*
1
X2*
2
X2*
3
...
X2*
n
*
X(]
Each
X2*
is the position for that rear panel
Input Select DIP switch from 1 to n. n = 3
for matrix sizes up to 1616, n = 6 for
matrix sizes of 1632 and larger.
X(
indicates whether the input level/peaking
is within the pre-determined threshold
for the input tied to output 1 only.
NOTE: This command is invalid for the MTPX Plus 128 only.
NOTE: X! = Input number 00 – (maximum number of inputs for your model)
X@ = Output number 01 – (maximum number of outputs for your model)
X( = Threshold 0 = outside of threshold 1 = within threshold
X2# = Global or room preset # 01 - 32 (global) or 01-10 (room)
X2% = Room # (for room presets) 10 max. (each can have up to 10 presets (X2#s) assigned
X2* = Local input select DIP switch status 0 = RJ-45 position 1 = local input position
