Information from LEDs and from the TEST Button: TEST Button to Print Main Status Pages or Quick Guide
D.2. TEST Button to Print Main Status Pages or Quick
Guide
The TEST button is located on the side of the unit. It is oper-
ated with a pen or similar pointed object.
When you want to print information using the TEST button, you
must make sure that the LED display shows the green light,
and only the green light, which indicates that the Unit is Ready.
.
The Main Status Pages describe all current configurations,
firmware release level and the content of the System Log
(errors, etc).since the last reboot.
The same Main Status Pages can also be printed from the
HTTP menu by choosing [Print Main Status Pages] from the
“Action” group.
The Quick Guide is a mini-manual meant to help you if it is not
convenient or possible to use the complete documentation.
The Quick Guide can also be printed from the HTTP menu by
choosing [Quick Guide] in the “Help” group.
Pressed while operational (“Ready”) Result
Press & hold 1-2 seconds for 1-2 seconds Print Main Status Pages (also called
Status Pages ).
Press & hold for at least 3 sec. Print on-board Quick Guide
