Figure B-25 Adding multipath volumes to an ASP
5. You will then be presented with a confirmation screen as shown in Figure B-26. Check the
configuration details and if correct, press Enter to accept.
Figure B-26 Confirm Add Units
Adding volumes to iSeries using iSeries Navigator
The iSeries Navigator GUI can be used to add volumes to the System, User or Independent
ASPs. In this example, we are adding a multipath logical volume to a private (non-switchable)
IASP. The same principles apply when adding multipath volumes to the System or User
ASPs.
Follow the steps outlined in “Adding volumes to an Independent Auxiliary Storage Pool” on
page 334.
Specify ASPs to Add Units to
Specify the ASP to add each unit to.
Specify Serial Resource
ASP Number Type Model Capacity Name
21-662C5 4326 050 35165 DD124
21-54782 4326 050 35165 DD136
1 75-1118707 1750 A85 35165 DMP135
F3=Exit F5=Refresh F11=Display disk configuration capacity
F12=Cancel
Note: For multipath volumes, only one path is shown. In order to see the additional
paths, see “Managing multipath volumes using iSeries Navigator” on page 349.
Confirm Add Units
Add will take several minutes for each unit. The system will
have the displayed protection after the unit(s) are added.
Press Enter to confirm your choice for Add units.
Press F9=Capacity Information to display the resulting capacity.
Press F12=Cancel to return and change your choice.
Serial Resource
ASP Unit Number Type Model Name Protection
1 Unprotected
1 02-89058 6717 074 DD004 Device Parity
2 68-0CA4E32 6717 074 DD003 Device Parity
3 68-0C9F8CA 6717 074 DD002 Device Parity
4 68-0CA5D96 6717 074 DD001 Device Parity
5 75-1118707 1750 A85 DMP135 Unprotected
F9=Resulting Capacity F12=Cancel
