SJ300 Inverter
Appendix B
B–9
The data in the receive frame contains 8-byte values for 13 items, listed in the table below:
The eight bytes for intelligent input or intelligent output data have a bit set in the data field for
each I/O point that is ON, according to the following table:
No. Monitor Item Units Multiplier
1 Output frequency Hz 100
2 Output current A 10
3 Direction of rotation
4 PID feedback monitor % 100
5 Intelligent input monitor
6 Intelligent output monitor
7 Frequency converting monitor 100
8 Output torque monitor % 1
9 Output voltage monitor V 10
10 Electric power monitor kW 10
11 Reserved
12 Run Mode time monitor hours 1
13 Power ON time monitor hours 1
Terminal Monitor Item Data
[FW] Forward input 00000001
[1] Input 1 00000002
[2] Input 2 00000004
[3] Input 3 00000008
[4] Input 4 00000010
[5] Input 5 00000020
[6] Input 6 00000040
[7] Input 7 00000080
[8] Input 8 00000100
[AL] Alarm relay 00000001
[11] Output 1 00000002
[12] Output 2 00000004
[13] Output 3 00000008
[14] Output 4 00000010
[15] Output 5 00000020
