6.1.1.2 Expansion Unit
The expansion unit shipping group contains:
•
An IBM 8285 Expansion Chassis with mounting brackets attached
•
A cable management bracket
•
A power cord suitable for the country
•
An expansion interface cable
•
An expansion connector wrap plug
6.1.1.3 Optional Items
Optional items include the following:
•
A 155 Mbps ATM I/O Card (MMF)
•
A 155 Mbps ATM I/O Card (SMF)
•
IBM 8260/8285 ATM Module(s)
•
Lobe Adapter Cables
− IBM ATM RJ-45 STP Adapter Cable (part number 42H0544)
− RJ-45 UTP Converter Cable (part number 10H3904)
Note
All data cables, including converter cables and crossover cables, must be
ordered separately.
6.1.2 Physical Specifications
The following sections describe the physical specifications of the IBM 8285.
6.1.2.1 Environmental Specifications
The 8285 switch does not require any special cooling. However, care should be
taken to ensure that its environment corresponds to the specifications listed in
Table 16.
Table 16 (Page 1 of 2). Environmental Specifications of the IBM 8285 Nways ATM
Workgroup Switch
Description IBM 8285 Base Unit Base plus Expansion
Operating Temperature 10•C to 40•C
(50•F to 122•F)
10•C to 40•C
(50•F to 122•F)
Storage Temperature 1•C to 60•C
(33.8•F to 140•F)
1•C to 60•C
(33.8•F to 140•F)
Operating Humidity 8% to 95%
(non-condensing)
8% to 95%
(non-condensing)
Air Exhaust 1.4m•/min 2.8m•/min
92 ATM Workgroup Solutions: Implementing the 8285 ATM Switch
