This soft copy for use by IBM employees only.
The commands we will need are:
•
SET DEVICE IP_ADDRESS
•
SET DEVICE DEFAULT_GATEWAY
•
SET DEVICE ARP_SERVER
•
SAVE ALL
•
SET DEVICE ATM_ADDRESS
•
SET PORT
The reason why SAVE ALL precedes SET DEVICE ATM_ADDRESS is that the
latter forces a reset of the ATM subsystem. You will be warned first, but if you
forget to save the parameters you have just entered, they will be lost; only the
ATM address will change.
Below is an annotated transcript of the commands used to configure and test our
simple network.
Table 32 (Page 2 of 2). Necessary Parameters for 8285 #1
Parameter Value Comments
ATM ESI 999999999901 6-byte MAC address.
ATM Selector 00 Has significance only to local
workstation. Should be set to
00.
ARP Server
ESI
08005A99029F 6-byte MAC address.
ARP Server
Selector
00 Must explicitly match the ARP
server′s value.
Chapter 7. IBM 8285 Configuration 125
