In This Chapter
Overview ................................................................................................ 241
Using the KSX II Local Console ............................................................ 241
KSX II Local Console Interface ............................................................. 242
Security and Authentication ................................................................... 242
Local Console Smart Card Access ........................................................ 243
Local Console USB Profile Options ....................................................... 244
Available Resolutions ............................................................................ 245
Port Access Page (Local Console Server Display) ............................... 246
Server Display ....................................................................................... 247
Hot Keys and Connect Keys .................................................................. 248
Supported Keyboard Languages ........................................................... 249
Special Sun Key Combinations ............................................................. 250
Accessing a Target Server .................................................................... 251
Returning to the KSX II Local Console Interface ................................... 251
Local Port Administration ....................................................................... 252
Resetting the KSX II Using the Reset Button ........................................ 256
Overview
The KSX II provides at-the-rack access and administration via its local
port, which features a browser-based graphical user interface for quick,
convenient switching between servers. The KSX II Local Console
provides a direct analog connection to your connected servers; the
performance is as if you were directly connected to the server's
keyboard, mouse, and video ports. The KSX II Local Console provides
the same administrative functionality as the KSX II Remote Console.
Using the KSX II Local Console
Simultaneous Users
The KSX II Local Console provides an independent access path to the
connected KVM target servers. For serial connections, the access path is
shared. Using the Local Console does not prevent other users from
simultaneously connecting over the network. And even when remote
users are connected to KSX II, you can still simultaneously access your
servers from the rack via the Local Console.
Chapter 13
KSX II Local Console
