INTRODUCTION
Thank you for choosing the Mitsubishi Transistorized VFD Setup Software.
This instruction manual gives handling information and precautions for use of this software. Incorrect handling might
cause an unexpected fault. Before using this product, please read this manual carefully to use it to the optimum.
Please forward this manual to the end user.
When reading this manual, note the following:
• This manual is written on the basis that Windows
®
XP Professional (English version) is the operating system.
• The [return] and [enter] keys are represented by the key.
• Drive D is described as the CD-ROM drive and Drive C as the hard disk drive.
• The screens, parameter names, set values and so on given in this manual are written on the basis of the FR-A700
series. When using the inverter of any other series, refer to the instruction manual of the used inverter.
Trademarks
• Microsoft, Windows and Excel are registered trademark or trademark of Microsoft Corporation in the United States
and/or other countries.
1)The formal name of Windows
®
98 is Microsoft
®
Windows
®
98 operating system.
2)The formal name of Windows
®
2000 is Microsoft
®
Windows
®
2000 operating system.
3)The formal name of Windows
®
Me is Microsoft
®
Windows
®
Me operating system.
4)The formal name of Windows
®
XP is Microsoft
®
Windows
®
XP operating system.
5)The formal name of Excel is Microsoft
®
Excel for Windows
®
.
• The "FR Configurator" is a registered trademark of Mitsubishi Electric Corporation.
The copyright and other rights of this software all belong to Mitsubishi Electric Corporation.
• No part of this manual may be copied or reproduced without the permission of Mitsubishi Electric Corporation.
• Other company and product names herein are the trademarks and registered trademarks of their respective owners.
• SPREAD
Copyright (C) 2004 FarPoint Technologies, Inc.
• LEADTOOLS
Copyright (C) 1991-2005 LEAD Technologies, Inc.
For Maximum Safety
• This product is not designed or manufactured to be used in equipment or systems in situations that can affect or
endanger human life.
• When considering this product for operation in special applications such as machinery or systems used in passenger
transportation, medical, aerospace, atomic power, electric power, or submarine repeating applications, please con-
tact your nearest Mitsubishi sales representative.
• Although this product was manufactured under conditions of strict quality control, you are strongly advised to install
safety devices to prevent serious accidents when it is used in facilities where breakdowns of the product are likely to
cause a serious accident.
<Abbreviations>
PU ............................................... Operation panel (FR-DU07) and parameter unit (FR-PU04/
FR-PU07)
Inverter................................... Mitsubishi inverter FR-A/F700 series
Pr. .......................................... Parameter Number
PU operation.......................... Operation using the PU (FR-DU07/FR-PU04/FR-PU07).
External operation.................. Operation using the control circuit signals
