Monitoring Inverter Status [Monitor]
REMARKS
Setting range and setting increments of "Sampling Interval" and "Time of Sampling"
"Sampling Interval" and "Time of Sampling" depend on Communication Port and Baud rate. Refer to the following table for
lower limit of "Sampling Interval".
Refer to the following table for maximum value, minimum value, and the Setting Increments of "Sampling Interval" and
"Time of Sampling" when the measurement conditions are actually set.
[Unit: ms]
*If the alarm trigger is set, the alarm trigger is also added to the measuring items.
Example: When connecting with RS-232 port, Baud rate is 19200bps, and monitoring "Output Frequency", "Output Current", and "Output
Voltage".
The lower limit of "Sampling Interval" = 100[ms]
The maximum value of "Sampling Interval" = 60000[ms]
The minimum value of "Sampling Interval" = 100 × 3 = 300[ms]
The setting increments of "Sampling Interval" = 50[ms]
The maximum value of "Time of Sampling" = 300 × 8192 = 2457600[ms]
The minimum value of "Time of Sampling" = 300 × 2 = 600[ms]
The setting increments of "Time of Sampling" = 100[ms]
Communication
Port
Baud rate
[bps]
Lower limit of
"Sampling Interval"
[ms]
RS-232C
300 2500
600 1300
1200 700
2400 350
4800 250
9600 150
19200 100
38400 100
USB - 50
Maximum value Minimum value Setting Increments
Sampling
Interval
60000
"Lower limit of Sampling Interval"
(the table above) × "the number of
the measuring items"*
50
Time of
Sampling
Sampling Interval × 8192 Sampling Interval × 2 Sampling Interval
