Chapter 9: AI2524 OSI/CLNP Configuration Steps
August 1997 Page 9-7
2524UM
This table shows a sample static routing table in which the nexthop
NETs are listed for completeness, but are not necessary to understand
the routing algorithm.
This table offers examples of how the longest matching NSAP prefix
can be matched with routing table entries in the table above.
Octet boundaries must be used for the internal boundaries of NSAP ad-
dresses and NETs.
Entry
NSAP Address
Prefix
Next-Hop NET
1 47.0005.000c.0001 47.0005.000c.0001.0000.1234.00
2 47.0004 47.0005.000c.0002.0000.0231.00
3 47.0005.0003 47.0005.000c.0001.0000.1234.00
4 47.0005.000c 47.0005.000c.0004.0000.0011.00
5 47.0005 47.0005.000c.0002.0000.0231.00
Datagram Destination NSAP
Address
Table Entry
Number Used
47.0005.000c.0001.0000.3456.01 1
47.0005.000c.0001.6789.2345.01 1
47.0004.1234.1234.1234.1234.01 2
47.0005.0003.4321.4321.4321.01 3
47.0005.000c.0004.5678.5678.01 4
47.0005.0001.0005.3456.3456.01 5
