Chapter 13: AI2524 Frame Relay Configuration Steps
August 1997 Page 13-5
2524UM
Configuration for Router 2
interface serial 0
ip address 131.108.64.1 255.255.255.0
encapsulation frame-relay
keepalive 10
frame-relay map ip 131.108.64.2 43
IPX Routing Example
This example illustrates how to send packets destined for IPX address
200.0000.0c00.7b21 out on DLCI 102:
ipx routing 000.0c00.7b3b
!
interface ethernet 0
ipx network 2abc
!
interface serial 0
ipx network 200
encapsulation frame-relay
frame-relay map ipx 200.0000.0c00.7b21 102 broadcast
Configure the
LMI
Local Management Interface (LMI) autosense enables the interface to
determine the LMI type supported by the switch and eliminates the
need to configure the Local Management Interface (LMI) explicitly.
Allow LMI Autosense to Operate
LMI autosense is active in these situations:
z
The router is powered up or the interface changes state to up.
z
The line protocol is down but the line is up.
z
The interface is a Frame Relay DTE.
z
The LMI type is not explicitly configured.
The LMI Autosense Process
When LMI autosense is active, it sends out a full status request, in all
3 LMI options (ANSI, ITU, Cisco) to the switch.
