AI2524 Router Card User’s Manual
Page 9-12 August 1997
2524UM
2. Configure the net for the process in area 2, doma in47.0004.004d:
net 47.0004.004d.0002.0000.0C00.0506.00
3. Specify iso-igrp routing using the previously specified tag castor :
interface ethernet 0
clns router iso-igrp castor
4. Specify iso-igrp routing using the previously specified tag castor :
interface ethernet 1
clns router iso-igrp castor
5. Specify iso-igrp routing using the previously specified tag castor:
interface serial 0
clns router iso-igrp castor
Example: Dynamic Routing in More Than One Area
Figure 9-6 and the example configuration illustrate how to configure
router named Router A that exists in two areas:
Figure 9-6:CLNS Dynamic Routing within Two Areas
.
