Chapter 9: AI2524 OSI/CLNP Configuration Steps
August 1997 Page 9-11
2524UM
You can assign a meaningful name for the routing process by using the
tag option. You can also specify a name for a NET in addition to an
address. For information on how to assign a name, see Specify Short-
cut NSAP Addresses.
You can configure an interface to advertise L evel2 information only.
This option reduces the amount of router-to-router traffic by telling th
Cisco IOS software to send out only L evel2 routing updates on certain
interfaces. Level 1 information is not passed on the interfaces for
which the Level 2 option is set.
In interface configuration mode, enable ISO IGRP on specified inter
faces and set the level type for routing updates:
clns router iso-igrp
tag
[level 2]
Example: Dynamic Routing within the Same Area
Figure 9-5, and the example configuration illustrate how to configure
dynamic routing within a routing domain. The router can exist in on
or more areas within the domain. The router named Router A exists in
a single area:
Figure 9-5:CLNS Dynamic Routing within a Single Area
1. Define a tag castor for the routing process:
router iso-igrp castor
