AI2524 Router Card User’s Manual
Page 9-60 August 1997
2524UM
TARP Configuration Task List
To configure TARP on the router, complete these tasks (only the first
task is required, all other tasks are optional):
z
Enable TARP and Configure a TARP TID
z
Disable TARP Caching
z
Disable TARP PDU Origination and Propagation
z
Configure Multiple NSAP Addresses
z
Configure Static TARP Adjacency and Blacklist Adjacency
z
Determine TIDs and NSAPs
z
Configure TARP Timers
z
Configure Miscellaneous TARP PDU Information
z
Monitor and Maintain the TARP Protocol
Enable TARP and Configure a TARP TID
TARP must be explicitly enabled before the TARP functionality be
comes available and the router must have a TID assigned. Also, before
TARP packets can be sent out on an interface, each interface must
have TARP enabled and the interface must be able to propagate TARP
PDUs.
The router will use the CLNS capability to send and receive TARP
PDUs. If the router is configured as an IS, the router must be running
IS-IS. If the router is configured as an ES, the router must be running
ES-IS.
1. In global configuration mode, turn on the TARP functionality:
z
Turn on the TARP functionality.
tarp run
z
Assign a TID to the router.
tarp tid
tid
2. In interface configuration mode, enable TARP on one or more in-
terfaces:
tarp enable
