C-7
MPX Plus 866 A Media Presentation Matrix Switcher • Reference Information
PRELIMINARY
Cables
When using signals with a scanning frequency of 15-125 kHz and running
distances of 100 feet or more, use high resolution BNC cables to achieve maximum
performance.
Bulk cable and termination tools
MHR mini high resolution cable Part number
MHRVGA/500 non-plenum 5-conductor, 500' (150 m) 22-024-01
MHRVGA/1000 non-plenum 5-conductor, 1000' (300 m) 22-024-03
MHRVGAP/500 plenum 5-conductor, 500' (150 m) 22-131-02
MHRVGAP/1000 plenum 5-conductor, 1000' (300 m) 22-131-03
MHR-2/250 non-plenum 2-conductor, 250' (75m) 22-123-02
MHR-2/500 non-plenum 2-conductor, 500' (150 m) 22-123-03
MHR-2P/250 plenum 2-conductor, 250' (75m) 22-129-02
MHR-2P/500 plenum 2-conductor, 500' (150 m) 22-129-03
RG6 super high resolution cable Part number
RG6/500 non-plenum 1-conductor, 500' (150 m) 22-098-02
RG6-1000 non-plenum 1-conductor, 1000' (300 m) 22-098-03
RG6P/500 plenum 1-conductor, 500' (150 m) 22-164-02
RG6P/1000 plenum 1-conductor, 1000' (300 m) 22-164-03
Termination tools and connectors Part number
15-pinHDconnectors,(VGAstyle),qty.10 100-070-51
CTU 200 universal crimp tool 100-241-01
MHR universal crimp term. kit (100 MHR BNC connectors) 100-266-01
RG6universalcrimpterm.kit(100RG6BNCconnectors) 100-267-01
CTU 100 universal compression tool (BNC, F, RCA) 100-181-01
MHR BNC compression kit (100 MHR BNC connectors) 60-538-01
RG6BNCcompressionkit(100RG6BNCconnectors) 60-538-02
Terminated cable assemblies
VGA male-to-male cables
VGAM-MMD, 3' to 100' (0.9 m to 30.4 m) (molded) 26-238-nn
VGAM-MBK, 3' to 100' (0.9 m to 30.4 m) (backshell) 26-238-nn
VGAPM-MMD, 3' to 25' (0.9 m to 7.6 m) (molded) 26-439-nn
VGAPM-MBK, 35' to 100' (10.6 m to 30.4 m) (backshell) 26-439-nn
