Lanier LP222cn Printer User Manual



Monitoring and Configuring the Printer
207
wins
Use the “wins” command to configure WINS server settings.
Viewing settings
msh> wins
If the IP address obtained from DHCP differs from the WINS IP address,
the DHCP address is the valid address.
Configuration
msh> wins “interface_name” {on | off}
{on} means “active” and {off} means “inactive”.
Be sure to specify the interface.
ip1394 can be specified only when the IEEE 1394 interface is installed.
wlan can be specified only when the IEEE 802.11b interface is installed.
Address configuration
Use the following command to configure a WINS server IP address:
msh> wins “interface_name” {primary|secondary} “IP ad-
dress”
auth {open|shared} You can set an authorization mode when us-
ing WEP. The specified value and authorized
mode are as follows:
open: open system authorized (default)
shared: shared key authorized rate
rate {auto|11m|5.5m|2m|1m} You can set the IEEE 802.11b transmitting
speed.
The speed you specify here is the speed at
which data is sent. You can receive data at
any speed.
auto: automatically set (default)
11m: 11 Mbps fixed
5.5m: 5.5 Mbps fixed
2m: 2 Mbps fixed
1m: 1 Mbps fixed
Interface name Interface configured
ether Ethernet interface
ip1394 IEEE 1394 interface
wlan IEEE 802.11b interface
Parameter Value configured
