Installing Options
45
F Install the IEEE 1394 interface board, IEEE 1284 interface board, IEEE
802.11b interface unit or Bluetooth interface unit.
Install the IEEE 1394 interface board, IEEE 1284 interface board, IEEE
802.11b interface unit or Bluetooth interface unit on the controller board.
The IEEE 1394 interface board and standard Ethernet interface cannot be
used at the same time.
Up to two of the following can be installed:
• IEEE 1394 Interface Board Type B
• IEEE 1284 Interface Board Type A
• IEEE 802.11b Interface Unit Type H
• Bluetooth Interface Unit Type 3245
G Install the network data protection unit (Network Data Protection Unit
Type C).
Insert the network data protection unit into the SD card slot on the controller
board.
Installing Options
Install options in the positions shown in the illustration.
❖ Exterior
1. AD440 (Duplex Unit)
Install this behind the front cover. Makes duplex prints.
See p.52 “
Attaching AD440 (Duplex Unit)”.
2. Paper Feed Unit Type 3000
Loads up to 530 sheets of paper.
