50 Mini Tower Computer
3
If necessary, disconnect any cables connected to the card.
4
Grasp the card by its top corners, and ease it out of its connector.
5
If you are removing the card permanently, install a filler bracket in the empty card-slot opening.
NOTE: Installing filler brackets over empty card-slot openings is necessary to maintain FCC certification of the
computer. The brackets also keep dust and dirt out of your computer.
6
Before you close the card retention mechanism, ensure that:
• The tops of all cards and filler brackets are flush with the alignment bar.
• The notch in the top of the card or filler bracket fits around the alignment guide.
7
Secure the card(s) by closing the card retention latch and snapping it into place.
8
Replace the computer cover (see "Replacing the Computer Cover" on page 297).
1 card retention latch 2 alignment guide 3 card
4 card-edge connector 5 card connector 6 release tab
2
3
1
5
4
6
