Renesas HD64F2111B Network Card User Manual



Rev. 1.00, 05/04, page 483 of 544
Register Name Abbreviation
Number
of Bits
Address Module
Data
Bus
Width
Number
of
Access
States
Keyboard control register H_1 KBCRH_1 8 H'FEDC Keyboard
buffer
controller_1
8 2
Keyboard control register L_1 KBCRL_1 8 H'FEDD Keyboard
buffer
controller_1
8 2
Keyboard data buffer register_1 KBBR_1 8 H'FEDE Keyboard
buffer
controller_1
8 2
Keyboard control register H_2 KBCRH_2 8 H'FEE0 Keyboard
buffer
controller_2
8 2
Keyboard control register L_2 KBCRL_2 8 H'FEE1 Keyboard
buffer
controller_2
8 2
Keyboard data buffer register_2 KBBR_2 8 H'FEE2 Keyboard
buffer
controller_2
8 2
DDC switch register DDCSWR 8 H'FEE6 IIC common 8 2
Interrupt control register A ICRA 8 H'FEE8 INT 8 2
Interrupt control register B ICRB 8 H'FEE9 INT 8 2
Interrupt control register C ICRC 8 H'FEEA INT 8 2
IRQ status register ISR 8 H'FEEB INT 8 2
IRQ sense control register H ISCRH 8 H'FEEC INT 8 2
IRQ sense control register L ISCRL 8 H'FEED INT 8 2
Address break control register ABRKCR 8 H'FEF4 INT 8 2
Break address register A BARA 8 H'FEF5 INT 8 2
Break address register B BARB 8 H'FEF6 INT 8 2
Break address register C BARC 8 H'FEF7 INT 8 2
Flash memory control register 1 FLMCR1 8 H'FF80 FLASH 8 2
Flash memory control register 2 FLMCR2 8 H'FF81 FLASH 8 2
Peripheral clock select register PCSR 8 H'FF82 PWM 8 2
Erase block register 1 EBR1 8 H'FF82 FLASH 8 2
System control register 2 SYSCR2 8 H'FF83 SYSTEM 8 2
Erase block register 2 EBR2 8 H'FF83 FLASH 8 2
Standby control register SBYCR 8 H'FF84 SYSTEM 8 2
