Front Panel Operation
Operation
To Initialize Agilent B2200
1. Press the Shift key and the Local key. Then the LCD will display NO.
2. Press the arrow key to displays YES, then press the
Enter key to initialize the
Agilent B2200, or press the
Exit key to cancel initialization.
To Enable Light Pen
Turn the Agilent B2200 off, and connect the light pen to the Light Pen connector at
the right down corner of the front panel. After that, perform the following procedure
to enable the light pen.
1. Press the
Menu key. The setup menu will be displayed on the LCD.
2. Press the arrow key to move the cursor to PEN, then press the
Enter key.
3. Press the arrow key to display ENABLE, then press the
Enter key to enable the
light pen, or press the
Exit key to cancel changing the setup.
NOTE Light Pen
You can control the Agilent B2200 functions and the switch connections by using
the front panel keys. And the Agilent B2200 allows you to use the Agilent 16443A
Light Pen to control the switch connections.
Pointing a LED on the LED matrix by using the light pen controls the setting of the
switch specified by the LED.
To Change Channel Configuration Mode
1. Press the Shift key and the Bias Mode key. The LCD displays the present setting
(AUTO or NORMAL).
2. Press the arrow key to select the mode, then press the
Enter key. The LCD
displays NO.
3. Press the arrow key to display YES, then press the
Enter key. Or press the Exit
key to cancel this operation.
Changing the channel configuration mode resets the Agilent B2200.
