3.8 UTOPIA Level 2 Interface
The IXP43X network processors support the industry-standard UTOPIA Level 2 bus
interface. A dedicated Network Processor Engine (NPE) handles segmentation and
reassembly of ATM cells, CRC checking/generation, and transfer of data to/from
memory. This allows parallel processing of data traffic on the UTOPIA interface,
off-loading processor overhead required by the Intel XScale
®
Processor.
The UTOPIA module is configured as a master and can support single-PHY (SPHY) or
multi-PHY (MPHY).
The IXP43X network processors are in compliance with the ATM Forum, UTOPIA Level 2
Specification, Revision 1.0. For optimal design results, the guidelines of the
specification should be followed.
3.8.1 Signal Interface
Table 14. UTOPIA Level 2/MII_A
Name
Type
Field
Pull
Up/
Down
Description
UTP_OP_CLK /
ETHA_TXCLK
IYes
UTOPIA Level 2 Mode of Operation:
UTOPIA Level 2 Transmit clock input. Also known as UTP_TX_CLK. This signal is
used to synchronize all UTOPIA Level 2 transmit output to the rising edge of the
UTP_OP_CLK.
MII Mode of Operation:
Externally supplied transmit clock.
• 25 MHz for 100 Mbps operation
• 2.5 MHz for 10 Mbps
When this interface/signal is enabled and is not being used in a system design,
the interface/signal should be pulled high with a 10-KΩ resistor.
UTP_OP_FCO TRI Yes
UTOPIA Level 2 flow control output signal. Also known as the TXENB_N signal.
Used to inform the selected PHY about data transmission. Placing the PHY’s
address on the UTP_OP_ADDR and bringing UTP_OP_FCO to logic 1 during the
current clock, followed by the UTP_OP_FCO going to a logic 0, on the next clock
cycle, selects the PHY that is active in MPHY mode.
In SPHY configurations, UTP_OP_FCO is used to inform the PHY that the
processor is ready to send data.
This signal is tied to Vcc with an external 10-KΩ resistor.
UTP_OP_SOC TRI Yes
Start of Cell. Also known as TX_SOC.
Active high signal is asserted when UTP_OP_DATA contains first valid byte of a
transmitted cell.
This signal is tied to Vss with an external 10-KΩ resistor.
UTP_OP_DATA[3:0] /
ETHA_TXDATA[3:0]
TRI No
UTOPIA Level 2 Mode of Operation:
UTOPIA Level 2 output data. Also known as UTP_TX_DATA. Used to send data
from the processor to an ATM UTOPIA Level 2-compliant PHY.
MII Mode of Operation:
Transmit data bus to PHY, asserted synchronously with respect to ETHA_TXCLK.
This MAC interface does not contain hardware hashing capabilities that are local
to the interface. In this mode of operation the pins represented by this interface
are ETHA_TXDATA[3:0].
†† Refer to the Intel
®
IXP43X Product Line of Network Processors Developer’s Manual for information on how to select an
interface.
