Intel
®
IXP43X Product Line of Network Processors
April 2007 HDG
Document Number: 316844; Revision: 001US 79
Hardware Design Guidelines—Intel
®
IXP43X Product Line of Network Processors
7.3.1.0.1 Printed Circuit Board Layer Stackup
The layer stackup used for the Intel
®
IXP435 Multi-Service Residential Gateway
Reference Platform is a 6-layer, printed circuit board with four signal layers and two
plane layers.
Details on the voltage reference layout are available in the CAD database or Gerber
files database for the Intel
®
IXP435 Multi-Service Residential Gateway Reference
Platform.
7.3.2 Timing Relationships
The routing guidelines presented in the following subsections define the recommended
routing topologies, trace width, spacing geometries, and typical routed lengths for each
signal group. These parameters are recommended to achieve optimal signal integrity
and timing.
All signal groups are length matched to the DDR clocks. The clocks on the processor
module are length matched to within ±10 mils of each other. Once this overall clock
length for any given DDR differential clock is determined, the command and control
signals can be routed to within the timing specified. A simple summary of the timing
results for each signal group is provided in Table 32 on page 80.
Control/Command Group to Clock Summary:
• The maximum allowable difference from any command/control signal to the clock is
±0.6 ns.
Table 31. DDR II/I SDRAM Interface -- Signal Timings
Symbol Parameter Minimum Nom. Maximum Units Notes
T
VB1
DQ, CB and DM write output valid time
before DQS.
1146 ps 1
T
VA1
DQ, CB and DM write output valid time after
DQS.
1146 ps 1
T
VB3
Address and Command write output valid
before CK rising edge.
3021 ps 1, 4
T
VA3
Address and Command write output valid
after CK rising edge.
3021 ps 1, 4
T
VB4
DQ, CB and DM read input valid time before
DQS rising or falling edges.
948 ps 2
T
VA4
DQ, CB and DM read input valid time after
DQS rising or falling edges.
948 ps 2
T
VB5
CS_N[1:0] control valid before CK rising
edge.
3021 ps 4
T
VA5
CS_N[1:0] control valid after CK rising edge. 3021 ps 4
T
VB6
DQS write preamble duration. 5625 ps 3
T
VA6
DQS write postamble duration. 3750 ps 3
T
V7
DQ, CB, and DM pulse width (tDIPW) 1750 ps 1
Notes:
1. See Figure 29, “DDR SDRAM Write Timings” on page 77
2. See Figure 30, “DDR SDRAM Read Timings” on page 77. The specified minimum requirements for “Data to
strobe read setup” and “Data from strobe read hold” are determined with the DQS delay programmed for
90 degree phase shift.
3. See Figure 31, “DDR - Write Preamble/Postamble Duration” on page 78
4. Address/Command pin group; RAS_N, CAS_N, WE_N, MA[13:0], BA[1:0]
5. Designed to JEDEC specification; it is recommended that IBIS models should be used to verify signal
integrity on individual designs
