IXP43X Product Line of Network Processors—Hardware Design Guidelines
Intel
®
IXP43X Product Line of Network Processors
HDG April 2007
86 Document Number: 316844; Revision: 001US
§ §
Series Resistor 20 Ω
Nominal Trace Width
1
Internal (Strip Line) 3.5 mils, External (Micro Strip) 5 mils
Nominal Pair Spacing (edge to edge)
2
Internal (Strip Line) 10.5 mils, External (Micro Strip) 10 mils
Minimum Pair to Pair Spacing Any layer 20mils
Minimum Spacing to Other DDR Signals 20.0 mils
Minimum Spacing to non-DDR Signals 25.0 mils
Maximum Via Count 5 per trace
Total Trace Length 1500 mils to 2500 mils
Table 36. DDRII Command Signal Group Routing Guidelines
Parameter Definition
Notes:
1. Nominal trace width is determined by board physical characteristics and stack-up. This value should
be verified with the PWB manufacturer to achieve the desired Zo.
2. Nominal pair to pair spacing is determined by board physical characteristics and stack-up. This value
should be verified with the PWB manufacturer to achieve the desired Zdiff.
