UTP_OP_DATA[4] /
ETHA_TXEN
TRI No
UTOPIA Level 2 Mode of Operation:
UTOPIA Level 2 output data. Also known as UTP_TX_DATA. Used to send data
from the
processor to an ATM UTOPIA Level 2-compliant PHY.
MII Mode of Operation:
Indicates that the PHY is being presented with nibbles on the MII interface.
Asserted synchronously, with respect to ETHA_TXCLK, at the first nibble of the
preamble, and remains asserted until all the nibbles of a frame are presented.
This MAC does not contain hardware hashing capabilities that are local to the
interface.
UTP_OP_DATA[7:5] TRI No
UTOPIA Level 2 Mode of Operation:
UTOPIA Level 2 output data. Also known as UTP_TX_DATA. Used to send data
from the
processor to an ATM UTOPIA Level 2-compliant PHY.
UTP_OP_ADDR[4:0] I/O Yes
Transmit PHY address bus. Used by the
processor when operating in MPHY
mode to poll and select a single PHY at any given time.
When this interface/signal is enabled and is not being used in a system design,
the interface/signal should be pulled high with a 10-KΩ resistor. When this
interface is disabled through the UTOPIA Level 2 and/or the NPE-A Ethernet soft
fuse and is not being used in a system design, it is not required for any
connection. Refer to Expansion Bus Controller chapter of the Intel
®
IXP43X
Product Line of Network Processors Developer’s Manual.
UTP_OP_FCI I Yes
UTOPIA Level 2 Output data flow control input: Also known as the TXFULL/CLAV
signal.
Used to inform the processor, the ability of each polled PHY to receive a complete
cell. For
cell-level flow control in an MPHY environment, TxClav is an active high tri-
stateable signal from the MPHY to ATM layer.
The UTP_OP_FCI is connected to multiple MPHY devices. It sees the logic high
generated by the PHY, one clock after the given PHY address is asserted and a
full cell can be received by the PHY. The UTP_OP_FCI sees a logic low generated
by the PHY one clock cycle, after the PHY address is asserted, and a full cell
cannot be received by the PHY.
When this interface/signal is enabled and is not being used in a system design,
the interface/signal should be pulled high with a 10-KΩ resistor. When this
interface is disabled through the UTOPIA Level 2 and/or the NPE-A Ethernet soft
fuse and is not being used in a system design, it is not required for any
connection. Refer to Expansion Bus Controller chapter of the Intel
®
IXP43X
Product Line of Network Processors Developer’s Manual.
UTP_IP_CLK /
ETHA_RXCLK
IYes
UTOPIA Level 2 Mode of Operation:
UTOPIA Level 2 Receive clock input. Also known as UTP_RX_CLK.
This signal is used to synchronize all UTOPIA Level 2-received inputs to the rising
edge of the UTP_IP_CLK.
MII Mode of Operation:
Externally supplied receive clock.
• 25 MHz for 100 Mbps operation
•2.5MHz for 10Mbps
This MAC interface does not contain hardware hashing capabilities that are local
to the interface.
When this interface/signal is enabled and is not being used in a system design,
the interface/signal should be pulled high with a 10-KΩ resistor.
Name
Type
Field
Pull
Up/
Down
Description
†† Refer to the Intel
®
IXP43X Product Line of Network Processors Developer’s Manual for information on how to select an
interface.
