S/UNI-QUAD
PMC-Sierra, Inc.
PM5349 S/UNI-QUAD
DATASHEET
PMC-971239 ISSUE 6 SATURN USER NETWORK INTERFACE (155-QUAD)
Proprietary and Confidential to PMC-Sierra, Inc., and for its Customers’ Internal Use
143
Register 0x67: RXCP Idle Cell Header Pattern
Bit Type Function Default
Bit 7 R/W GFC[3] 0
Bit 6 R/W GFC[2] 0
Bit 5 R/W GFC[1] 0
Bit 4 R/W GFC[0] 0
Bit 3 R/W PTI[3] 0
Bit 2 R/W PTI[2] 0
Bit 1 R/W PTI[1] 0
Bit 0 R/W CLP 1
GFC[3:0]:
The GFC[3:0] bits contain the pattern to match in the first, second, third, and
fourth bits of the first octet of the 53-octet cell, in conjunction with the Idle Cell
Header Mask Register. The IDLEPASS bit in the Configuration 2 Register
must be set to logic zero to enable dropping of cells matching this pattern.
Note that an all-zeros pattern must be present in the VPI and VCI fields of the
idle or unassigned cell.
PTI[2:0]:
The PTI[2:0] bits contain the pattern to match in the fifth, sixth, and seventh
bits of the fourth octet of the 53-octet cell, in conjunction with the Idle Cell
Header Mask Register. The IDLEPASS bit in the Configuration 2 Register
must be set to logic zero to enable dropping of cells matching this pattern.
CLP:
The CLP bit contains the pattern to match in the eighth bit of the fourth octet
of the 53-octet cell, in conjunction with the Match Header Mask Register. The
IDLEPASS bit in the RXCP Configuration 2 Register must be set to logic zero
to enable dropping of cells matching this pattern.
