General Specifications
CL-S6621 1-6
Outline of electronic devices
CPU 32-bit RISC CPU
ROM Standard equipment: FLASH ROM 16MByte (User area: 4MByte)
RAM Standard equipment: SDRAM 32MByte (User area: 4MByte)
Media detection sensors
Transparent sensor Detects media gap between labels, notches on tags, and media out
Reflective sensor Detects reflective mark on back of media and media out
PNE (Paper Near
End) sensor
Detects the near end state of roll paper
(By default, issuing a paper near end alarm is disabled by the menu
settings.)
Label peeling sensor *
1
Detects labels that are peeled off.
Communication interfaces
Serial 2400, 4800, 9600, 19200, 38400, 57600, or 115200 bps
USB High-speed USB2.0 (480Mbps)
Communication interface (Options)
Parallel*
8
IEEE1284 (Compatible, Nibble, ECP mode)
Wired LAN:
Ethernet interface (10-Base-T/100-Base-TX)
Network
Wireless LAN:
IEEE802.11n/IEEE802.11g/IEEE802.11b
Indications and switches
LED POWER, PRINT, CONDITION, ERROR
Buzzer Alarms, errors, etc.
Operating panel keys PAUSE, FEED, STOP, MODE/REPEAT
Head-up detection
switch
Detects head open.
Power switch Turns power on and off.
Power supply
120V (-10%+6%), 2.5A, 60Hz (U.S.A., Canada) 120V version
UL60950-1st/2nd Edition, CSA No. 950, FCC Part 15 Subpart B
(Class A)
220V-240V (-10%+6%), 1.5A, 50/60Hz (Europe) 220V version
EN60950-1, EN55022 (Class A), EN55024, EN61000-3-2,
EN61000-3-3, CCC GB4943-2001/GB9254-1998/GB17625.1-2003
Power consumption (max. value)
120V version 105W (operation at 6 IPS at 12.5% printing duty)
4.4W (printer standby in Normal mode)
2.3W (printer standby in Standby mode*
9
)
220V version 105W (operating at 6 IPS at 12.5% printing duty)
5.0W (printer standby in Normal mode)
2.8W (printer standby in Standby mode*
9
)
*8: This interface is Non-L. P. S. (Limited Power Source).
*9: Standby mode is default OFF.
