magicolor 330 - Base Engine Service Manual 3-19
Primary FIPS: Error Messages
3.16 - Error Message: Used OPC End of Life
The OPC Drum installed is not new.
Logic control on the MCU PWB detected that the installed OPC Drum is not new.
Step Actions and Questions Yes No
SUSPECT COMPONENTS
The following components are associated with this specific prob-
lem. One or more of these components may have failed partially or
completely. If you cannot isolate the problem using this FIP,
replace each component listed below, one at a time, until the prob-
lem disappears.
• Wiring and connectors linking the components
1
Replace the OPC Drum (RRP 9.48) with a Cartridge that is recom-
mended for use with this printer.
Does the error message still appear?
Go to step 2 Problem
solved
2
MCU PWB INSPECTION
1. Switch off the printer.
2. Follow RRP 9.123 to access the MCU PWB.
3. Disconnect P/J 16 from the MCU PWB.
4. Reconnect P/J 16 to the MCU PWB.
5. Switch on the printer.
Does the error message still appear?
Go to step 3 Problem
solved
3
Replace the MCU PWB (RRP 9.123)
Does the error message still appear?
Go to suspect
components
Problem
Solved
