magicolor 330 - Base Engine Service Manual 3-43
Primary FIPS: Error Messages
3.38 - Error Message: Call for Service High Density, continued
Step Actions and Questions Yes No
6
DEVELOPER HOUSING INSPECTION
Hand rotate the Rotary Frame Assembly and inspect the
magnet roll of each of the four Developer Housings for dam-
age and toner leakage.
Are the Magnet Rolls free of obvious damage and the area
immediately around the Roll is relatively clean?
Go to step 7 Replace the
Developer in
the Housing or
replace the
Developer
Housing Assy.
(RRP 9.59)
7
Replace the OPC Drum (RRP 9.48)
Does the error message still appear?
Go to step 8 Problem
solved
8
Replace the HVPS (RRP 9.120)
Does the error message still appear?
Go to suspect
components
Problem
solved
