Chapter 11 Illustrated Parts List 11-3
TABLE 11-1 System Unit Replaceable Components
Numerical
Reference Component Description
1 2.1-Gbyte SCSI assembly Hard disk drive
1 4.2-Gbyte SCSI assembly Hard disk drive
1 9.1-Gbyte SCSI assembly Hard disk drive
2 Hard drive bay with SCSI Mechanical hard drive housing
3 PCI fan assembly PCI fan
4 CD-ROM drive 12X-speed CD-ROM drive
4 4-mm tape drive 4-Gbyte/8-Gbyte, 4-mm tape drive, DDS-2
4 4-mm tape drive 12-Gbyte/24-Gbyte, 4-mm tape drive, DDS-3
4 8-mm tape drive 14-Gbyte, 8-mm tape drive
5 Manual eject floppy Diskette drive
6 DC switch assembly DC switch assembly
7 Speaker assembly Speaker
8 Peripheral power cable Peripheral power cable
9 Foot Chassis foot
10 Power supply Power supply, 300 watts
11 TPE cable (category 5) Provides Ethernet interconnection
12 NVRAM/TOD Time of day, 48T59, with carrier
13 Motherboard System board
14 PCI card Generic
15 Graphics card Vertical, single buffer UPA graphics card
15 Graphics card Vertical, double buffer plus Z (DBZ) UPA
graphics card
