13. Specifications
Pin No.
Spec
3
B(BLUE)/PB/CB
4
GND
5
GND
6
GND
7
GND
8
GND
9
DDC 5V
10
GND
11
GND
12
DDC Data
13
HD/CS
14 VD
15
DDC Clock
COMPUTER/COMPON ENT VIDEO DVI-D IN (HDCP) (DVI-D 24-pin)
1724
16
9
8
1
Image 13-4
Pin No.
Spec
1
TMDS DATA 2-
2
TMDS DATA 2+
3
TMDS DATA 2 Shield
4
-
5
-
6
DDC Clock
7
DDC Data
8
-
9
TMDS DATA 1-
10
TMDS DATA 1+
11
TMDS DATA 1 Shield
12
-
13
-
14 +5V Power
15
Ground (for +5V)
16 Hot plug detection
17
TMDS DATA 0-
18
TMDS DATA 0+
19
TMDS DATA 0 Shield
20
-
21
-
22
TMDS Clock Shield
23
TMDS Clock+
24
TMDS Clock-
R5905597 PHXX SERIES 28/01/2014 117
