10. Lamp replacement
Image 10-1
10.3 Lamp replacement
CAUTION: Only authorized service perso nnel are allowed to remove the covers.
How to replace
1. Unplug the power c ord from the outlet or appliance inlet.
2. Loosen two s crews (a) on the rear and two screws (b) on the side that are securing the side cover (c) using a Phillips screwdriver.
(c)
(b)
(a)
Image 10-2
3. Slide and remove the side cover towards the rear.
Image 10-3
4. Loosen two s crews (d) that are securing the lamp cover using a Phillips screwdriver and remove the lamp cover (e) from the
projector.
94
R5905597 PHXX SERIES 28/01/2014
