Brother ADS2000 Scanner User Manual



Scan Documents Longer than Letter
file:///C|/Documents%20and%20Settings/mcampbell.AM/My%20Documents/ADS2000solutions/chapter3_3_9.html[3/11/2013 10:25:27 AM]
5
Select Long Paper (Normal Width) or Long Paper (Narrow Width) from the Document Size drop-down list.
Note
Each Long Paper option can scan a large document up to the following size:
Long Paper (Normal Width): 8 1/2 × 34.0 in. (215.9 × 863.0 mm)
Long Paper (Narrow Width): 4 1/4 × 34.0 in. (107.9 × 863.0 mm)
If you cannot select Long Paper, uncheck the Duplex(two-sided) Scanning and Auto Deskew check box.
6
Change other settings if needed (see Change Scan Settings).
7
Click the button you selected in step 4.
The message dialog appears. Click the Start Scanning button.
The machine starts scanning.
Note
Check the Don’t show me again. check box not to show the message dialog again.
Support the document with your hand if the document is longer than the Top Cover.
