An Electronic Industries Association (EIA) serial digital interface standard specifying the characteristics of
the communication path between two devices using either D-SUB 9 pins or D-SUB 25 pins connectors.
This standard is used for relatively short-range communications and does not specify balanced control
lines. RS-232 is a serial control standard with a set number of conductors, data rate, word length and type
of connector to be used. The standard species component connection standards with regard to computer
interface. It is also called RS-232-C, which is the third version of the RS-232 standard, and is functionally
identical to the CCITT V.24 standard. Logical ’0’ is > + 3V, Logical ’1’ is < - 3V. The range between -3V
and +3V is the transition zone.
SMTP (Simple Mail Transfer Protocol) is a TCP/IP protocol used in sending E-mail.
A snapshot is a collection of settings at a given point of time for a conguration
Subnet mask
A number that is used to identify a subnetwork so that IP addresses can be shared on a local area network.
Tool tip
Pop up information when moving the mouse pointer over a menu item or an icon in the tool bar.
tpi le
Device plug-in le for Projector Toolset.
A window represents the active area of an input source.
Window texture
Background of window representation in Layout preview. The texture can be a color or a picture.
Workspace explorer
Window to manage the available congurations in the current workspace.
