- 205 -
(9) Writable character set: 42 (24×24 dots )
Nibble mode
1
30H
2
30H
3
30H
4
30H
5
30H
6
30H
7
30H
8
30H
9
33H
•
•
•
•
•
137 30H 138 30H
139 30H 140 30H 141 30H 142 30H 143 30H 144 30H
Hex. mode
1
00H
2
00H
3
00H
4
00H
5
3CH
6
00H
•
•
•
•
67
00H
68
3CH
69
00H
70
00H
71
00H
72
00H
[Nibble mode]
(1) The writable character data to be stored is separated into four dot units and sent in the
following order (1
→
144). (High order digit: “3”)
(2) The data of writable characters to be stored is 30H to 3FH.
(3) The data count of writable characters to be stored should be 144 bytes.
[Hex. mode]
(1) The writable character data to be stored is separated into eight dot units and sent in
the following order (1 → 72).
(2) The data of writable characters to be stored is 00H to FFH.
(3) The data count of writable characters to be stored should be 72 bytes.
* When writable character 42 is designated, the width and height of the character are both
24 dots.
Character width 24 dots
Character
height
24 dots
444 4 4 4
8 8 8
