92 Operation
Chapter 4 - System Configuration
Auto Channel Select – Enables the AP to automatically select an unoccupied radio
channel. (Default: Enabled)
Transmit Power – Adjusts the power of the radio signals transmitted from the
access point. The higher the transmission power, the farther the transmission
range. Power selection is not just a trade off between coverage area and maximum
supported clients. You also have to ensure that high-power signals do not
interfere with the operation of other radio devices in the service area. (Options:
100%, 50%, 25%, 12%, minimum; Default: 100%)
Maximum Station Data Rate – The maximum data rate at which the access
point transmits unicast packets on the wireless interface. The maximum
transmission distance is affected by the data rate. The lower the data rate,
the longer the transmission distance. (Default: 54 Mbps)
Antenna ID – Selects
the antenna to be used
by the AP. The optional
external antennas that
are certified for use
with the access point are listed in the drop-down menu. Selecting the correct
62.437
72.442
82.447
92.452
10 2.457
11 2.462
12 2.467
13 2.472
14 2.482
NOTE
Check your country’s regulations to see if Auto Channel can be disabled.
Table 4-4: Channels Assignment
Channel NumberV Frequency (GHz)
