220 Operation
Chapter 5 - Command Line Interface
Example
5.18.9 antenna control
This command selects the use of two diversity antennas or a single antenna for
the radio interface.
Syntax
antenna control <diversity | left | right>
• diversity - The radio uses two identical antennas in a diversity mode.
• left - The radio uses a single antenna on the left side. Select this method when using an optional
external antenna that is connected to the left antenna connecto
r.
• right - The radio uses a single antenna on the right side. Select this method when using an
optional external antenna that is connected to the right antenna connector.
Default Setting
Diversity
Command Mode
Interface Configuration (Wireless)
Command Usage
The antenna ID must be selected in conjunction with the antenna control method to configure
proper use of any of the antenna options.
Example
5.18.10 antenna id
This command specifies the antenna type connected to the AP represented by a
four-digit hexadecimal ID number.
Syntax
antenna id <antenna-id>
• antenna-id - Specifies the ID number of an approved antenna that is connected to the AP
(Range: 0x0000 - 0xFFFF)
Default Setting
0x0000 (None). The unit will not transmit until an antenna is defined
Command Mode
Interface Configuration (Wireless)
Command Usage
• The optional external antennas (if any) that are certified for use with the AP are listed by typing
antenna control id ?. Selecting the correct antenna ID ensures that the AP's radio transmissions
are within regulatory power limits for the country of operation.
• The antenna ID must be selected in conjunction with the antenna control method to configure
proper use of any of the antenna options.
Enterprise AP(if-wireless g)#preamble short
Enterprise AP(if-wireless g)#
Enterprise AP(if-wireless g)#antenna control right
Enterprise AP(if-wireless g)#
