DISASSEMBLY AND ASSEMBLY
3.2.3 Housing Removal
This section describes how to remove the housing.
3.2.3.1 Top Cover Removal
0 Two people are required to remove the top cover; one person must hold the top cover wf~;k the other
ll
person removes the screws. M the top cover is not supported while the screws are removed, the
weight of the top cover may damage the rear hinges.
1
Step 1: Open the top cover.
Step 2: While someone supports the top cover. remove the four screws (two on the right and two on the
left) securing the top cover to the hinges and remove the cover.
Figure 3-16. Top Cover Removal
Rev. A
3-13
