the stream. The Auto CRC check box specifies if a valid CRC will be automatically
generated for the stream.
Stream Buttons
The
Add, Add File..., Modify, Delete, and Edit Data... buttons perform functions for a
single stream.
Transmission Mode and Status Controls
The
Transmission Mode radio buttons control how many times all streams are
transmitted once they are loaded to the module. You can transmit the entire
specification n times or continuously. The transmission mode is not part of the
Transmit Specification when saving to a file and must be set each time you load the
Transmit Specification.
The
Transmission Status section provides information about the number of
activated streams, speed of transmission, and the amount of module memory used
by active streams.
Transmit Specification Control Buttons
The
Load Module, Open Specs, and Save Specs buttons perform functions on a
complete Transmit Specification. Be sure to use the
Load Module button to load the
specification to the module before you begin transmission. The
Template button
allows you to use predefined data as a starting point for new stream. It also lets you
create Magic Packets
™.
Table 8-1. Stream Function Buttons
Stream Button Stream Function
Add Adds a new stream after the currently selected stream in the Defined
Streams window. The values displayed in the fields of the Transmit
Specification window are used as the values for the new stream.
Add File… Adds a new stream defined by capture file (.CAP or .HST file) in the
Defined Streams window. A dialog box appears asking for the name
of the capture file. The first packet in the capture file is the defined
stream. All subsequent packets in the capture file are ignored.
Modify Changes the definition of the current stream. The values displayed in
the fields of the Transmit Specification window overwrite the values
of the currently selected stream.
Delete Deletes the currently selected stream.
Edit Data… Brings up the packet editor. You can use the packet editor to modify
the currently selected stream.
