11-22
Surveyor
User’s Guide
Table 11-8. H.323 Call Field Descriptions
Field Name Description
Frame ID Frame ID of the first frame from which the conversation was detected.
This field is useful when doing post capture analysis. If there is a need
for in-depth analysis of a specific call, the first frame associated with
call can be quickly determined.
Source Reference Value The Call Reference Value for the conversation used by H.225.0 on the
source side.
Source Address The IP address of the initiator of the call.
Source Q.931 Port The Q.931 TCP port of the initiator of the call.
Source H.245 Port The H.245 TCP port of the initiator of the call.
Source Number Phone number of the initiator of the call.
Source Alias An alias of the initiator of the call.
Source H.323 Ver The version of H.323 being used by the initiator of the call.
Source Product The product being used by the initiator of the call.
Product Version The product version being used by the initiator of the call.
Start Time Time at which the call was started.
Stop Time Time at which the call was completed.
Setup Time (ms) Time that was taken for the call to be setup (the time taken from the
start of the call until the phone rings).
Destination Reference
Value
The Call Reference Value for the conversation used by H.225.0 on the
destination side.
Destination Address The IP address of the receiver of the call.
Destination Q.931 Port The Q.931 TCP port of the receiver of the call. This port has a default
value of 1720.
Destination H.245 Port The H.245 TCP port of the receiver of the call
Destination Number Phone number of the receiver of the call.
Destination Alias An alias of the receiver of the call.
Destination H.323 Ver The version of H.323 being used by the receiver of the call.
Destination Product The product being used by the receiver of the call.
Product Version The product version being used by the receiver of the call.
Fast Start Indicates whether or not Fast Start was used during call setup.
Release Code Code indicating the status of the call when it was completed.
