PhaserShare Networking Manual
143
Printer Management
13
162 Fuser Remaining (%) The percentage of life remaining in the fuser unit.
163 Imaging Unit
Remaining (%)
The percentage of life remaining in the imaging unit.
164 Transfer Kit
Remaining (%)
The percentage of life remaining in the transfer kit unit.
165 Fuser Roll
Remaining (%)
The percentage of life remaining in the fuser roll unit.
166 Main Charge Grid
Remaining
The percentage of life remaining for the main charge
grid.
171 Doors Open For each access door, the number of times it has been
opened.
172 Consumables
Replaced
A distribution of the conditions at which each
consumable has been replaced, whether it was low or
out or neither (i.e. at the user’s discretion), or some
other condition detected by the printer.
173 Paper Out For each tray, the number of times it has been emptied.
174 Button Presses The number of times any of the front panel buttons has
been pressed.
175 Feature A distribution of how many times the user has accessed
front panel menu settings or printed internal help pages.
181 Power On Count The number of times the power has been switched on.
182 Total On Time (hrs) Total time the printer has been on, in hours.
183 Latest On Time (hrs) Time the printer has been on since just the last time it
was switched on.
184 EStar Time (hrs) Total time the printer has been in Energy Star mode, in
hours.
185 EStar Time
Distribution (mins)
A distribution of the time the printer has spent in Energy
Star mode. For example: 15-29:5 indicates that there
were 5 periods of Energy Star lasting between 15 and
29 minutes.
186 Warmup Time (hrs) Total time the printer has been in the warmup state, in
hours.
187 Offline Time (hrs) Total time the printer has been unavailable for printing,
in hours.
188 JetStack Standby
Time (hrs)
Total time the printer has been in JetStack Standby
mode, in hours.
189 JetStack Standby
Time Distribution
(mins)
A distribution of the time the printer has spent in
JetStack Standby mode. For example: 15-29:5
indicates that there were 5 periods of JetStack Standby
lasting between 15 and 29 hours.
191 Temperature (C) A distribution of hourly temperature readings.
For example: <=10:2 indicates that the engine
temperature was less than or equal to 10 degrees
Celsius for 2 hours.
Usage profile full report - some fields not supported by all printers (cont'd.)
Field
number Field name Description
